XVM Vibrator Motor

Availability:
Quantity:

24 hours continuous working

We choose High purity silicon steel plate; its thickness is thin to 0.5mm. High stacking assembling coefficient, flat and uniform, results in generating less heat and lower iron loss during running, which makes it more suitable for 24 hours continuous working.

(All processing conform to CHINA GB2521-88 standard.)


Apply to severe environment

100% pure copper coil provides better thermal conductivity, longer life than aluminum wire, and the surface of coil is painted with anti-mildew coverage, which makes it also work well in hot environment and hot & humid environment (Support ambient temperature to 50°).


More Safety

With special flanging protective cover + stainless steel outgoing line, our lowest protection grade is IP 55, support to customize IP65 for dust, moist, etc., bad working environment.


Longer Life

Our bearing chooses Chinese Top bearing brand (ZWZ, HRB, TWB), working life is not less than 8000 hours. Support optional SKF, NSK bearing.


Appearance

Our casting uses resin sand casting technical, which make sure the casting’s surface is more flat and smooth, with advanced painting technical, that is why our motor appearance looks brighter and more beautiful.

It is special asynchronous vibrating source uniting motive power source and vibrating source into once, it can be used to equip in vibration sieve, vibration feeder, vibration conveyor, vibration platform, etc.


Rated voltage: 110-550V Rated frequency: 50/60Hz Phase: Three

Protective grade:IP55 Insulation grade:F Work systemSI

Ambient temperature: below 40°C Altitude: below 1000m
